HW Audio:. Citronic U-PAD USB Mixer

Free Shipping

List price: ~~£89.00~~

Our Price: £ 79.94

Shipping: £0.00 *

MPN: 170.879UK

Brand: Citronic

EAN: 5015972212769

Availability: Out of Stock. Call us for availability.

* Shipping price shown uses the cheapest domestic shipping service. More options available at checkout.

Highlights

Individually switchable 48V phantom power
Supplied with USB lead for power and PC/Mac connection
High quality digital stereo input and output via USB
Studio quality balanced analogue inputs & outputs

U-PAD Compact Mixer with USB Interface

Compact audio mixer with 2 mono inputs and a stereo line input. Both mono channels have a combo XLR/jack input with individually switchable mic/instrument impedance and +48V phantom power for the XLR connector. High/Low EQ and Pan controls are present on all mono and stereo input channels and a digital input from USB can be routed to main output or phones for monitoring. Analogue output is delivered on a pair of balanced XLR connectors and digitally to the USB for recording. When powered from a laptop USB port, the U-PAD offers high quality recording capability in any environment, even on location.

High quality digital stereo input and output via USB
Studio quality balanced analogue inputs & outputs
Individually switchable +48V phantom power
Supplied with USB lead for power and PC/Mac connection

Power supply:    5.5Vdc (USB)
Gain:    -14 to +40dB
EQ: low:    ±15dB @ 80Hz
EQ: high:    ±15dB @ 12kHz
Phantom power:    +48V individually switchable (XLR inputs only)
Input impedance : mic:    2k Ohms
Input impedance : instrument:    1M Ohms
Input impedance : line:    20k Ohms
Frequency response:    20Hz - 20kHz (±0.5B)
THD +N:    <0.03% @ 1kHz
Dynamic range:    102dB
Crosstalk : stereo:    92dB
Output:    Left + Right balanced XLR (analogue)
Output impedance:    120 Ohms
USB computer interface:    Duplex stereo in/out AD/DA
Sampling format:    24-bit, 96kHz max.
Dimensions:    171 x 166 x 66mm
Weight:    900g
